In Retrospect...

So here we are...

At the end of another semester and at the precipice of another learning curve, I find myself reflecting back on the lessons I've learned about Intermediate Graphics, where they're headed in the industry and what purpose they serve in the real world. While this course has taken me through the ins and outs of the OpenGL Graphics Pipeline, how it's used and what we can do with it, I found that I have learned so much more from pouring my mind out and opening up to let the world in on my manner of thinking and the way I choose to express myself. For me, these blogs have been more than just another grade for a passing mark. They've been an exploration of a world I would have never known existed had I not dared to step into it. They have been an avenue for me to speak my mind and share my opinions and more than ever they've been a way for me to study topics I thought far beyond my scope of understanding. Over the past few months I've touched on a lot of important developments in graphic technologies. From game engines to lighting in real-time, from global illumination to Screen Space Ambient Occlusion. And what have I gained putting hours of my life into these blogs if not an insight into a world of graphical prowess that has amazed and kept me wanting more.

Shaders

What started out as a simple way to tell the world about graphical implementations I've been making for homework assignments soon become a deeper discovery of the nature of shading techniques and how they can be used efficiently and effectively to produce stunning and captivating visual feats that push the boundaries of current-generation consoles and make it possible to replace flaws with beautiful graphic effects.

So what is a shader? Let's go back to the basics. A shader is any program that is part of the graphics pipeline and is capable of communicating with a computer's GPU (Graphical Processing Unit). The two primary shaders I focus on in most of blog posts are the Vertex and Fragment shaders. Of course, there are about four or five different types of shaders, but those are beyond the scope of this course (although very cool to play around with and implement). The vertex shader handles the position of all vertices travelling through the pipeline. The job of the vertex shader is mainly to bring vertices form objects space to screen space using the ModelViewProjection matrix which quite basically allows the viewer to perceive the vertices in a reasonable are within their computer screens. These are then passed on with properties such as texture coordinates and colours to the fragment shader where the real magic happens.

The fragment shader is in charge of accepting fragments from the rasterizer and compiling them into complete primitives on screen using pixels in the frameBuffer as well as interpolation between the vertex colours. The idea behind fragment shaders is not to simply produce the same pixel colour set for the vertex upon entering the shader. Instead, the fragment shader is most commonly used in combination with VBOs (Vertex Buffer Objects), VAOs (Vertex Array Objects), and FBOs (Frame Buffer Objects) to effectively create all kinds of neat graphical effects from motion blur to depth of field and everything in between.

For really interesting graphic techniques such as bloom or shadow mapping multiple passes will afford you information to store on FBOs - this may be depth or a colour texture. The way you make use of your Frame Buffer Objects is ultimately upto you. Possibly one of the most important lessons and the biggest take away from the course is that once you have a solid framework set up, shaders are all about math and figuring out how to mathematically compute certain attributes based on light, position and colour information. After that, it's all about playing around with parameters, clamps and ranges in order to get your desired effect.

Although there has never been any set-in-stone ways for using a shader, they are typically used to either make things more realistic or far more unrealistic. This returns to the same  discussion visited and re-visited countless times on my blog. Are post-processing effects a good thing or a bad thing? Do they add to the realism of a game or take away from it? Do they aid gameplay or heavily distract the player from their objective? Well, truth be told the answer is always the same. MODERATION. Shader effects are a terrific way of graphically simulating real-time physics in object interaction and the way light behaves relative to a material's properties. On the other hand, effect like colour grading, toon shading and bloom can be seen as flashy, unnecessary and annoying when used excessively or in the wrong context. Balance is always key when exploiting powerful technology and there must always be a fine line game developers should be weary not to cross for the sake of boasting superior graphical achievements which put them ahead of competitors.

Frameworks

Oh for the glory of these nifty little programmable devices which aid heavily in the creation of an interactive environment with support for external classes - from shaders to FBOs. Over the course of this semester I have learned to appreciate the role frameworks play in the everyday world of intermediate graphics. A good framework is a versatile one which may be adapted or even built upon to improve the structure to better suit your current needs. In the simplest of terms, a framework is a foundation of support for attempting various graphical techniques as well as debugging should problems arise in your game engine. I have always wished that we had a formal class or tutorial session where we were specifically taught to build frameworks and use them for our shaders throughout the year. This would have been not only helpful but would have opened up a world of exploration for us earlier on in the semester. With that said, I do believe that Frameworks are done best when they are made to suit your needs and your needs alone. You are going to be the end user so you'd better make sure you're comfortable with what your framework supports and what it doesn't.

In retrospect, the process of building your very own framework helps one understand the structure and processes involved with graphical effect implementations and using shaders, FBOs, VBOs and the lot. Additionally, the more time you spend on your framework, the more you understand it inside out and the more you begin to perceive the reward of generalizing your code to fit your needs and staying away from hard-coding in any context.

A framework allows you control of your shader implementations and in essence makes you an expert at understanding the graphical pipeline. This is important because a lot of the user-friendly functionality is working towards being deprecated in favor of functionality that puts far more control in the hands of users. If it isn't all that clear as of yet, I'm talking about the move from 'GLSL #version 120' to 'GLSL #verison 330 core'. Here users are allowed to create their own matrices to be used in vertex and fragment shaders and are, in a sense, made to comprehend the reason the processes work the way they do.

Toggles are always a good idea when it comes to frameworks and are encouraged in lieu of the importance of testing parameter and thresholds. Many game engines, in fact, begin as framework and develop as functionality is gradually added over time. As a foundation, with frameworks, there's nowhere to build but up.

Game Engines

I have picked up some real jewels of wisdom over these past few months when it comes to game engines and their development. One of the first and most important lessons I've learnt is that a good game engine can take several years to build. It is about dedication and a willingness to put effort into making your engine more accessible for other people to use. This will not only help you delegate work in a team environment but will make it easier for you to build off of your code in later years. A good game engine is like a good framework, a sturdy foundation upon which to develop efficient coding practices.

Taking a loser look at game engines over the course of the blogs I've written in the past few months, I have learned a lot about how game engines come to be conceived and the sheer manpower it takes to build them. An important lesson in building game engines is to make the lives of your fellow developers as easy as possible. Giver artists more control and they will reward you with the beauty you want to see in-game. In my personal experience, I have picked up more than a few tips here and there in regards to building game engines. For starters, nothing should ever be hard-coded. If it takes up more than ten lines then find a function or a class for it. Generalize your classes and structs as much as possible and don't ever code for the possibility of a single scenario - have a contingency plan for every possible outcome.

Another important lesson which comes with experienced coding is the notion of planning before the code is written. It is always important to analyze what you need, why you need it and what your plan of implementation is. By writing out your designs on paper and running through the obvious and not-so-obvious logical errors, you will save a lot of time debugging. It is also crucial to remember, as briefly mentioned earlier, programming a game engine is very difficult work. You must always aim to start ahead of time in addition to being determined to keep at it until all the kinks have been worked out. Always keep your code clean, commented and readable with formatting good enough for your mother to understand.

In Conclusion

I have got to say that I haven't had more fun doing homework then when I do hoguework. It's not only about getting the work done. It's about going out there, finding what the web has to aid you and then attempting to figure out what it all means. The tutorials were brilliant and really helped introduce me to the world of shading. Eventually I began coding  shaders myself and after the initial rough start with FBOs I grew into a natural groove and couldn't stop with so much to experiment with and tons of shaders to try out.

I have learnt a lot in the past few months and have enjoyed sharing my experience with the world and the worldwide web. With over 1000 views, I guess they seemed to like it too!

Lighting & materials for real-time game engines...

Complex rendering

Ever since the dawn of Programmable Pipelines the aim of the gaming industry has been to implement real-time rendering techniques for complex materials. Games have strived to make lighting, reflections and material displays as feasible as possible on real-time game engines. We can talk all day about pre-rendered cutscenes and how gorgeous they look, but the real test is what we can do with lighting in-game. The following blog investigates methods used to adapt and simplify complex skin rendering models to fit current game engines.

Information on this blog is credited to and referenced from Tobias Kruseborn's Master's Thesis on 'Lighting and materials for real-time game engines,' at the School of Computer Science and Engineering Royal Institute of Technology in the year 2009. A link to his thesis can be found here.

The theories and applications in this blog will be quite involved and detail-oriented. It is important to keep this mind in going forth. With that said, as always, I will try to make it as fun as possible - Enjoy the blog!

Introduction

While the aim of this blog is to examine the implementation of advanced real-time rendering techniques for complex materials such as human skin, it includes determining whether spherical harmonics and Wavelets may be used to represent both diffuse and specular reflection for environmental lighting in a real-time game engine.

The problem being addressed here is how to lighten materials with several layers in a physically correct manner as well as in real-time. To begin to understand the goals in mind behind this exploration let's take a look at NVIDIA's Doug Jones demo which attempted to realistically model the actor's head in real-time.

The preceding demo sets a very clear standard for high quality shading in real-time. However, it is important to consider that "real-time" for a tech demo is much different from being fast enough to use in a game which is where most people would need to use this technology. Think about the fact that this demo fully taxes the processor of a high-end graphics card whereas most games run on much less powerful consoles. Commercial games must further render entire worlds which leaves a small fraction for skin shading.

Now let's talk about theory.

Diffuse and specular reflection

Specular light on human skin is admittedly easier to represent than the diffuse reflection. This is based on the fact that specular light reflects directly and isn't absorbed into the surface. This specular light only reflects 6% of the entire light spectrum this is because the ole layer of the skin doesn't give out a mirror-like reflection due to roughness. The Blinn-Phong model leads to an incorrect estimate since it outputs more power than it receives and further fails to capture increased specularity on grazing angles. The use of a more precise physical base reflection factor model can improve this quality in exchange for a few more Shader instructions.

Representing diffuse reflection is much more fundamentally difficult due to the fact that in order to calculate diffuse of one area on the skin, we would need to know the incoming light intensity of nearby points. So, we use a diffuse profile which provides an approximation for the manner in which light scatters underneath the surface of a highly scattering translucent material. When rendering materials by applying a diffuse profile, all incoming light converges at the surface before dispersing to create the exact shape of the profile. Luckily, the problem of finding a scattering dipole is almost solved. The dipole curve plotted for the diffuse profile can be approximated by summarizing a number of Gaussian functions.

To implement this, we convert the diffuse illumination of geometry to a light map several times with Gaussian blur and then combine them together. We can then perform the Gaussian convolution.

By carefully choosing a sampling pattern, we can then represent each Guassian blur with a 12 jitter sample. The first selection represent the incoming and outgoing light directly and the following six samples corresponds to middle-level scattering. The last six samples represent the high-level scattering and are mainly used for red light. The result is a variety of blurs for each channel which can be done on a single pass.

Modified translucent shadow maps

In texture-space diffusion, some regions that are near one another in Euclidean space can be far apart in texture space. For example, ears and noses may not take into consideration transmitters from both sides causing scattering to only be observed in the part that is targeted tot he light. A translucent shadow map (TSM) makes depth, irradiance and the surface normal to store these quantities on the surface to the light at each pixel in the texture.  At run-time, each surface is in shadow so we can study the textur to find the distance to the object from the light and access the convolved version of irradiance of the light surface.

Environment lighting

The goal behind environmental lighting is to be able to represent both diffuse and specular reflection from an environment map in real-time. In representing alight with an environment map, all texels become a light source - we need to integrate light from all directions. This is not trivial to do and it is important to keep in mind that specular reflection is also view-dependent.

The median cut algorithm effectively converts an HDR light probe image to a set of light sources by dividing a light sensor image into a number of regions followed by the process of creating a light source corresponding to direction, size, color and intensity of the total incoming light in each region. With the help of a summed area table, we find the longitude, latitude n in a picture with the highest intensity through a binary search per region in n iterations. This is the quickest and most accurate way to find areas with the same intensity. The final algorithm successfully represents complex environment lighting with a few point lights.

Spherical Harmonics (SH) is the angular portion of the solution to the Laplace equation in spherical coordinates. The SH basis is an orthogonal function on the surface of a sphere. It is similar to the canonical basis of R3, but differs in the sense that each of the SH coefficients do not correspond to a single direction, but to values of an entire function over the whole sphere. SH basis functions are small pieces of a signal that can be united to an approximation of the original signal. To create an approximation signal using the SH basis, we must have a scalar value for each base that represents how the original function is similar to the basis function.

There are 3 components to an SH basis. Diffuse, area specular and analytical specular. We must first separate the material into diffuse parts and low and high frequency glossy parts. We then use an SH irradiance environment map for diffuse reflection and a new area specular model for low frequency gloss. Finally, the Bidirectional Reflectance Distribution Function (BRDF) is evaluated directly with point lights for high frequency.

Spherical harmonics are good for representing low frequency light, but not high frequency light. Wavelets can capture both low and high frequency light in a compact manner. Wavelets are a set of non-linear bases. When projecting a function in terms of wavelets, the wavelet basis functions are chosen according to the functions being approximated.

Some waves are small and can represent just a pixel while other bigger waves can capture light from the whole environment. This way, we can represent an environment map with only a few wavelet coefficients. Some will represent just a pixel in an environment while other will represent frequencies over the whole surrounding. The Haar wavelet lies in the planar domain and leads to distortion when used for functions in other domains, but the Soho wavelet lies in the spherical domain so these are used more often.

The following is the rendering of environment lighting with diffuse and specular relfection along with Soho wavelets. From (a) to (e) the number of lights in the scene are 8, 16, 32, 256 and 512.

Final Algorithm

Combining all the methods and techniques previously discussed, the final algorithm used in skin rendering looks something like this:

• Use the median cut algorithm to get our light source positions.

• Convert the diffuse light from an environment map to spherical harmonics.

• Do this for each light.

• Render a shadow map and apply Gaussian blur filter to it.

• Render the shadows and the diffuse light to a light map.

• Apply Separable Subsurface Scattering (SSS) to the light map.

• Apply SSS for translucency.

•  Read the diffuse light and shadow from the light map.

• Add the rest of the mesh texture to the diffuse light.

• Calculate the specular light from the same positions as the shadows.

• Combine the specular and diffuse light to a final color.

At the end of the day, here are the kind of results we're looking at with the Kelemen-Szmirnay-Kalos model on the left versus the Phong model on the right:

In conclusion

Some noted observation based on the result of the skin rendering algorithms mentioned in the this blog include the fact that diffuse reflections make the skin look more natural and the method implemented is ten times faster that the Doug Jones demo. The method can be used in real-time game engines, especially for cutscenes. In terms of specular reflection, the Kelemen-Szmirnay-Kalos model gave better results and made the specular reflection look more realistic than when using the Phong model. It was also able to catch reflections at grazing angles. Translucent shadow mapping yielded unsatisfying results when implemented with a jitter kernel and if the results were to be compare to the extra cost of computing the TSM, the conclusion would be that the modified TSM is not worth using in game engines.

Shadows were distinctly improved when applying a Gaussian shadow map filter instead of using a uniform shadow map filter. The combination of Gaussian shadow maps and subsurface scattering provided soft shadows without artifacts. The median cut algorithm can be used for many purposes and was very accurate and helpful since it could be used as positions for shadow maps and point specular reflections. The approximation method for Soho wavelets is quite expensive, but it can be run in real-time with the light coming from a whole environment map. Finally, representing the BRDF model in spherical harmonics was seen to be an efficient and low storage technique for environment lighting.

After having explored the rich and vast world of lighting and materials, it is plain to see that with a few clever techniques and algorithms we can quite easily represent realistic light in real-time game engines. It is a fascinating process and one not to be taken for granted. I hope all the theory in this blog has not put you off from trying it yourself. I would advise you to read Mr. Kruseborn's paper for a much more detailed explanation of the algorithms and techniques before you dive right into real-time lighting.

We are on the precipice of creating games that look like movies, it is time to take the leap.
